Convective Clouds

Convective clouds forming over the Amazon in a blanket of smoke. Photo credit: Prof. Ilan Koren, Weizmann Institute of Science.

Weizmann Institute research shows how atmospheric particles affect cloud formation in real time

Understanding how clouds affect the climate has been a difficult proposition. What controls the makeup of the low clouds that cool the atmosphere or the high ones that trap heat underneath? How does human activity change patterns of cloud formation? The research of the Weizmann Institute of Science’s Prof. Ilan Koren suggests we may be nudging cloud formation in the direction of added area and height. He and his team have analyzed a unique type of cloud formation; their findings, which appeared recently in Science, indicate that in pre-industrial times, there was less cloud cover over areas of pristine ocean than today.

In order to form, clouds need tiny particles called aerosols that rise in the atmosphere. These aerosols – natural ones like sea salt or dust, or human-made ones like soot – form nuclei around which the cloud droplets condense. In relatively clean environments, clouds can only grow as large as the amount of aerosols in the atmosphere allows: They are the limiting factor in cloud formation.

The question is: Does the current load of aerosols in the atmosphere already exceed that limit, in which case adding extra particles should not greatly affect cloud formation; or do they continue to be a limiting factor as pollution rises, so that added aerosols would continue to influence the clouds? A model developed by Prof. Koren and his team showed that an increase in aerosols, even in relatively polluted conditions, should result in taller, larger clouds that rain more aggressively. But proving the model was another story: Experimenting on clouds, or even finding ways to isolate the various factors that go into their formation in real time, is a highly difficult undertaking.

Prof. Koren, research student Guy Dagan, and Dr. Orit Altaratz in the Department of Earth and Planetary Sciences looked to an unlikely place to test their model: near the horse latitudes. These are subtropical regions far out in the oceans that, in the past, were reviled by sailors because the winds that filled their sails would die out there for weeks on end. Here was a lab for the scientists to test the basic physics of their model: an atmospheric region controlled by well-defined meteorological conditions, which was sometimes pristine, sometimes containing low levels of aerosols. If the model was correct, transitions from one to the other should be dramatic. The team also wanted to test out their theory on the clouds that do form in this region – warm, convective clouds that are fuelled by the ocean’s moisture.

With other potential factors – wind, large temperature swings, or land formations – out of the way, the team could concentrate on the aerosols, comparing daily satellite images of cloud cover and measurements of the aerosol load to the predictions of the model. Using many different types of analysis, they found that their model closely matched the satellite observations.

They then looked at another source of data: information from the Clouds and the Earth’s Radiant Energy System (CERES) satellite instruments, which measure fluxes of radiation, both reflected and emitted, from the Earth to space, to help scientists understand how the climate varies over time. When analyzed together with the aerosol loading over the same area at the same time, the outcome, says Prof. Koren, was a “textbook demonstration of the invigoration effect” of added aerosols on clouds. In other words, the radiation data fit the unique signature of clouds that were growing higher and larger. Such clouds show a strong increase in cooling due to the reflected short waves, but that effect is partly cancelled out by the enhanced, trapped, long-wave radiation coming from underneath.

Over the oceans, at least, the pre-industrial cloud conditions would have been considerably different from those of today; this implies that the aerosols we have been adding to the atmosphere may have had a significant effect on global patterns of cloud formation and rain.

Says Prof. Koren: “We showed that convective clouds do not necessarily stop being aerosol-limited; under relatively polluted conditions the increase in aerosol loading will make the clouds taller, larger, and their rain-rate stronger. As the area of this cloud cover grows, it reflects more of the shortwave radiation; but as the clouds get taller, their greenhouse effect becomes more significant, counteracting about half of their total cooling effect.”

Prof. Ilan Koren’s research is supported by the J & R Center for Scientific Research and the estate of Raymond Lapon.
